Post: 8' to 12' tall options. 12 ga. Galvanized stud with receptors for the tread bracket at every 8” allowing multiple height adjustments without the aid of bolts or pins. The post can also be used horizontally as a whaler when required to straighten any necessary wiggles over window openings. An ancillary post foot can be purchased to attach post base to footings or floors if necessary. The weight of the post is 18# and stacks in a minimal space. With this system you will find you make half as many trips from the truck and or trailer to the project.

Tread Bracket: Is 12 ga. Galvanized lightweight steel and attaches without the aid of pins or bolts. They store in a small space and can be transported to the site in groups of 5 in each hand making less trips in and out. This bracket has many features listed in the installation guide.

Extendable Turnbuckle: Epoxy powder coated square tube steel for maximum strength. This quick turn adjustable turnbuckle comes with Zinc plated feet and heads utilizing ¾ coil thread rod for minimal jamming. The pivoting foot is equipped with 4-holes for screwing to a deck and also a 7/8 diameter hole for use with a curb pin/nail The head attaches to the tread bracket with no bolts or pins. The standard turnbuckle is extendable from 7’ to 12’ and is expandable up to 30' with optional components.

CONTACT US TODAY! 877.525.4466
Superior Alignment Systems ICF Wall Bracing comes as a package consisting of these three components:
